System Controller: Single ctrl

Processor:
Avago12Gb SAS3

Memory:
N/A

HBAs & RAID Cards Support

Broadcom (LSI) 12Gb/s & 6Gb/s SAS HBAs

Broadcom (LSI) 12Gb/s & 6Gb/s RAID Cards

ATTO 12Gb/s & 6Gb/s SAS HBAs

ATTO 12Gb/s & 6Gb/s RAID Cards

Expansion Connectivity (per Controller)

5 x 12Gb/s SAS3 wide ports (SFF-8644)
Slide RAIl kit (optional)

Host Ports: N/A

Drive Type: 16 bay
3.5"/2.5" 12Gb SAS/NL SAS
2.5" SAS/SATA SSD* (Need optional MUX board)
Max. Drives Supported: N/A

Power Supply
80 PLUS Platinum, two redundant 770W (1+1)
